Hybrid Inverter

(Euro-Standard)

Utilize free and clean solar energy, improve energy independence and reduce energy costs with the hybrid inverter - EU, the perfect solution for PV and battery energy storage management.

Product Description

Product Specifications

PDF Download

maidian
maidian
maidian

LCD
Operation

  • Convenient to set up parameters through LCD panel easily

  • Easy-accessible button operation

maidian
LCD<br>Operation
maidian
maidian

App Monitoring

  • Full visibility & Remote operation

  • Check the running status at anytime

  • Optimize storage settings from anywhere

maidian

Friendly & Flexible

  • Support multi-parallel connection

  • Support flexible access of generator

maidian

ESS SOLUTION

maidian

Utilize Free & Clean Solar Energy
As Much As Possible

maidian
  • Morning

    Minimal solar generation, high demand.

  • Midday

    Maximum solar generation, low demand.

  • Evening

    Minimal solar generation, highest demand.

PV

  • Max. Input Power (W)

    7000
  • Max. Input Voltage (V)

    550
  • MPPT Voltage Range (V)

    125 - 500
  • PV Terminal Type

    MC4
  • Start Operation Voltage (V)

    125
  • Max. Input Current (A)

    2 * 14
  • Max. Short Current (A)

    2 * 17.5
  • No. of MPPT

    2
  • No. of String per MPPT

    1
  • DC Switch

    Integrated

Battery

  • Battery Type

    LFP (Integrated BMS)
  • Nominal Voltage (V)

    48
  • Operation Voltage Range (V)

    40 - 58
  • Max. Charge / Discharge Power (W)

    6000 / 6000
  • Max. Charge / Discharge Current (A)

    95 / 110
  • Battery Charge Method

    Self-adaption to BMS

AC (Grid)

  • Nominal Apparent Power (VA)

    6000
  • Max. Apparent Power (VA)

    6000
  • Max. Active Power (W)

    6000
  • Max. Input Power (VA)

    6000
  • Grid Type

    Single Phase
  • Nominal Frequence (Hz)

    50 / 60
  • Grid Voltage Range (V)

    176 - 270
  • Nominal Voltage (V)

    230
  • Frequence Range (Hz)

    45 - 55 / 55 - 65
  • Max. Output Current (A)

    26
  • Max. Input Current (A)

    26
  • THDI (Rated power)

    < 3%
  • PF

    - 0.8 ~ + 0.8
  • Switch Time

    < 20 ms

AC (Back up)

  • Max. Active Power (W)

    6000
  • Nominal Frequence (Hz)

    50 / 60
  • Frequence Accuracy (Hz)

    ± 0.1
  • Nominal Voltage

    230
  • Max. Output Current (A)

    26
  • Voltage Accuracy

    ± 1%
  • THDV (100%R Load)

    < 2%
  • Output Parellel (Pcs)

    6
  • Over Load

    105% < Load ≤ 110%, 30S; 110% < Load ≤ 120%, 10S; 120% < Load ≤ 150%, 0.02S

Efficiency

  • Max. Efficiency (BAT to AC)

    95%
  • Max. Efficiency (PV to AC)

    97.6%
  • CEC. Efficiency

    97%
  • Max. MPPT Efficiency

    99.9%

Protections

  • GFCI

  • Anti-islanding Protection

  • PV String Input Reverse Polarity Protection

  • Output Over Voltage Protection

  • Output Over Current Protection

  • Output Short Protection

  • Insulation Resistance Detection

  • DC / AC Surge Protection

    Type 3

General Data

  • Dimension (W * D * H) (mm)

    550 *200 * 515
  • Net Weight (kg)

    25
  • Operating Temperature Range

    -25 ~ 60℃ (45℃ derating)
  • Relative Humidity

    0 ~ 95% (non-condensing)
  • Max. Altitude (m)

    > 2,000 Derating
  • Electronics Protection Degree

    IP65
  • Topology Type

    Transformerless, Isolation (Bat to AC)
  • Night Self Consumption (W)

    < 3
  • Cooling

    Natural
  • Noise (dB)

    < 35
  • HMI

    APP / LCD
  • COM

    RS485 / CAN / WiFi / 4G (Optional)

Certifications

  • Safety

    EN 62109-1 / 2,IEC / EN62477-1
  • EMC

    IEC / EN 61000-6-1, IEC / EN 61000-6-3
  • Grid Code

    South Africa NRS097-2-1:2017, UK G98, G99

Warranty (Years)

  • Warranty (Years)

    5 / 10 (Optional)
