Model

SAT24205 / SAT24230

Platform Voltage (V)

24

Rated Voltage (V)

25.6

Rated Capacity (Ah)

206 / 230

Rated Energy (kWh)

5.28 / 5.89

Weight (kg)

41 ± 1 / 42 ± 1

Dimension (Included Post Terminal, mm)

523 x 269 x 222

Continuous Charging Current (A)

100

Max. Cranking Current (A)

2500

Working Voltage Range (V)

24.8 ~ 29.2

Working Temperature Range (℃)

-40 ~ 60

Max. Charging Voltage (V)

32

Force Start Function

Yes

Bluetooth Function

Yes

Heating Function

Yes

Built-in Fire Extinguishing System

Yes

APP

Yes

OTA

Yes

Ingress Rating

Yes

Model

KPC-25DF / BN3Y-XK

Power (V)

24

Nominal Cooling Capacity (W)

2500

Nominal Cooling Power Consumption (W)

950

Nominal Cooling Current Consumption (A)

33.3

EER (W/W)

2.5

Max. Output Power (W)

1040

Refrigerant

R134a / 500g

Air Volume (Interior Unit) (m³/h)

430

Noise Level (dB)

52

Dimension (W x H x D, mm)

902 x 880 x 186

Net Weight (kg)

39.5

Allowable Overpressure at Discharge/Suction Side (MPa)

2.2 / 1.0

Max. Allowable Pressure at High/Low Pressure Side (MPa)

2.2

Max. Operating Pressure of Heat Exchanger (MPa)

2.2
