5.12kWh Wall-Mounted LiFePO4 Battery PowerBase 5

Compact yet powerful, the ROYPOW 5.12kWh wall-mounted LiFePO4 battery is designed for off-grid living, rural homes, and solar-powered cabins. Featuring Grade A LFP cells, it offers over 6,000 charge cycles and a 10-year lifespan, while delivering stable, reliable energy for essential appliances and daily use, day or night, with or without the grid. Backed by 10 years of warranty.

  • Product Description
  • Product Specifications
  • PDF Download
Grade A LFP Cell

Grade A LFP Cell

  • background
    Upper Cover Protection
    for Terminals
  • background
    Up to 16 Units
    in Parallel
  • background
    >6,000 Times Cycle Life
  • background
    10 Years Warranty
  • Support Automatic DIP Switch Address Allocation

    Support Automatic DIP Switch Address Allocation

  • Compatible with Leading Inverter Brands

    Compatible with Leading Inverter Brands

  • Support Wi-Fi Remote App Monitoring & OTA Upgrades

    Support Wi-Fi Remote App Monitoring & OTA Upgrades

  • Grade A LFP Cell

    Grade A LFP Cell

    Model PowerBase 5
      • Electric Data

      Nominal Energy (kWh) 5.12
      Usable Energy (kWh) 4.79
      Depth Of Discharge (DoD) 95%
      Cell Type LFP (LiFePO4)
      Nominal Voltage (V) 51.2
      Operating Voltage Range (V) 44.8~56.8
      Max. Continuous Charge Current(A) 100
      Max. Continuous Discharge Current(A) 100
      Scalability 16
      • General Data

      Weight (Kg / lbs.)
      50 / 110.23
      Dimensions (W × D × H) (mm / inch) 510 x 510 x 166 / 20.08 x 20.08 x 6.54
      Operating Temperature (°C) 0~ 55℃ (Charge), -20~55℃ (Discharge)
      Storage Temperature (°C)
      Delivery SOC State (20~40%)
      >1 Month: 0~35℃; ≤1 Month: -20~45℃
      Relative Humidity ≤ 95%
      Altitude (m / ft) 4000 / 13,123 (>2,000 / >6,561.68 derating)
      Protection Degree IP 20
      Installation Location Indoor
      Communication CAN, RS485, WiFi
      Display LCD
      Certificates UN38.3, IEC61000-6-1/3
    • File Name
    • File Type
    • Language
    • pdf_ico

      5.12 kWh 11.7kWh 16kWh LiFePO4 Battery

    • EN
    • down_ico
    5.12kWh Wall-Mounted LiFePO4 Battery PowerBase 5
    5.12kWh Wall-Mounted LiFePO4 Battery
    5.12kWh LiFePO4 Battery

    FAQ

    • 1. Can off-grid inverter work without battery?

      +

      Yes, it’s possible to use a solar panel and inverter without a battery. In this setup, the solar panel converts sunlight into DC electricity, which the inverter then converts into AC electricity for immediate use or to feed into the grid.

      However, without a battery, you can’t store excess electricity. This means that when sunlight is insufficient or absent, the system won’t provide power, and direct use of the system may lead to power interruptions if sunlight fluctuates.

    • 2. How long do off-grid batteries last?

      +

      Typically, Most solar batteries on the market today last between 5 and 15 years.

      ROYPOW off-grid batteries support up to 20 years of design life and over 6,000 times of cycle life. Treating the battery right with proper care and maintenance will ensure a battery will reach its optimal lifespan or even further.

    • 3. How many batteries do I need for off-grid solar?

      +

      Before you can determine how many solar batteries are required to power your home, you need to consider a few key factors:

      Time (hours): The number of hours you plan to rely on stored energy per day.

      Electricity demand (kW): The total power consumption of all the appliances and systems you intend to run during those hours.

      Battery capacity (kWh): Typically, a standard solar battery has a capacity of about 10 kilowatt-hours (kWh).

      With these figures in hand, calculate the total kilowatt-hour (kWh) capacity needed by multiplying the electricity demand of your appliances by the hours they’ll be in use. This will give you the required storage capacity. Then, assess how many batteries are needed to meet this requirement based on their usable capacity.

    • 4. What is the best battery for off-grid solar system?

      +

      The best batteries for off-grid solar systems are lithium-ion and LiFePO4. Both outperform other types in off-grid applications, offering faster charging, superior performance, longer lifespan, zero maintenance, higher safety, and lower environmental impact.
